P-Series USB Insertion Reader
4
SPECIFICATIONS
Table 1-2 lists the specifications for the USB P-Series Insert Reader.
Table 1-2. Specifications
Reference Standards ISO 7810 and ISO 7811, AAMVA & JISB9561*
Power Input 5V from USB port
Recording Method Two-frequency coherent phase (F2F)
Message Format ASCII
Card Speed 3 to 50 IPS
Head Life 1,000,000 passes (500,000 insert cycles)
ELECTRICAL
Current
Normal Mode
Suspend Mode
30 mA
300 uA
MECHANICAL
Weight 3.74 oz. (106.03 g)
Dimensions See Appendix A
Cable length Optional
ENVIRONMENTAL
Temperature
Operating -40
o
F to 185
o
F (-40
o
C to 85
o
C)
Storage -40
o
F to 185
o
F (-40
o
C to 85
o
C)
Humidity
Operating 10% to 90% noncondensing
Storage 10% to 90% noncondensing
* ISO (International Standards Organization), AAMVA (American Association of Motor Vehicle
Administrators) and JIS B9561 (Japanese Industrial Standard).
