Page 4 MNVCCBZ_0828
Description of the CBZ220/CBZ24 keyboard
The CBZ220/CBZ24 keyboard is a professional product for applications within the sphere of safety and
surveillance. In a safety system, it allows the control of one pan & tilt motor with 230/24Vac power supply and the
control of the zoom lens functions ZOOM, FOCUS, IRIS.
The keyboards is supplied in two versions: for 230Vac pan & tilt control, and for 24Vac pan & tilt control (refer to
identification data).
WARNING: before the connection, make sure that the output voltage of the CBZ220/CBZ24 keyboard
corresponds to pan & tilt voltage (Refer to the identification data of the keyboard and pan & tilt motor).
Features:
• 5 Pan & tilt control functions: UP, DOWN, LEFT, RIGHT, AUTO
• 6 Zoom lens control functions: ZOOM IN, ZOOM OUT, IRIS OPEN, IRIS CLOSE, FOCUS NEAR, FOCUS FAR
• Zoom lens control with polarity inversion or common ground power supply
• 230Vac pan & tilt motion control (refer to identification data)
• 24Vac pan & tilt motion control (refer to identification data)
• Easiness of use
Appliances which can be connected to the CBZ220/CBZ24 keyboard
• PTH910-PTH911 pan & tilt: Outdoor Pan & Tilt; 230/24Vac pan & tilt for outdoor installations with PAN (horizontal
movement) and TILT (vertical movement) functions and AUTOPAN (horizontal automatic movement)
• IPT720-IPT721 pan & tilt: Indoor Pan & Tilt; 230/24Vac pan & tilt for indoor installations with PAN (horizontal
movement) and TILT (vertical movement) and AUTOPAN (horizontal automatic movement) functions.
• PTH310 / PTH311 pan & tilt: Outdoor/Indoor Pan & Tilt; 230/24Vac pan & tilt for outdoor and indoor installations
with functions: PAN (horizontal movement), TILT (vertical movement) and AUTOPAN (horizontal automatic
movement )
