Videotec NTM - Manual (Page 9)

EN - English - I
nstruc
tions manual
7
9.2 Mechanical
2 cable glands: 2xPG13.5 in nickel-plated brass for
external connections
External body polishing
9mm (0.3in) thick front and back flange
O-ring gaskets
Internal usable area (WxH): 88x86mm (3.5x3.4in)
Internal usable length
NTM 334mm (13.1in)
Internal usable length with heater and/or power supply
NTM 245mm (9.6in)
Unit weight: 6kg / 13.3lb
Germanium Glass Window
2mm (0.07in) thick, Ø 70mm (2.8in) external, Ø 55mm
(2.1in) internal
External non-scratch treatment (hard carbon coating)
Internal antireflection treatment
Spectral range from 7.5 to 14μm IR range
Average transmission from 7.5 to 11.5μm, 94%
Average transmission from 11.5 to 14μm, 90%
Wiper
Wiperblade and enclosure constructed from AISI 316
stainless steel
Dimensions (ØxL): 100x169mm (3.9x6.6in), not
comprehensive of blade
Connector 3+1 pins
IN 230Vac, consumption 7W max
IN 24Vac, consumption 7W max
9.3 Electrical
Heater Ton 15°C ±3°C (59°F ±37°F) Toff 22°C ±3°C (71°F
±37°F)
- IN 12Vdc/24Vac, consumption 20W max
- IN 115/230Vac, consumption 40W max
Camera power supply
- IN 100-240Vac - OUT 12Vdc, 50/60 Hz, 1A
- IN 230Vac - OUT 24Vac, 50/60Hz, 400mA
9.4 Environment
Indoor / Outdoor
Operating temperature with heater: -20°C / +60°C (-4 /
+140° F)
9.5 Compliance to
NTM
CE according to EN61000-6-3, EN60065, EN50130-4
IP66/IP67 according to EN60529
VIPNX
CE according to EN61000-6-3, EN60065, EN50130-4
IP66 according to EN60529
8 Disposal of waste
materials
g n This symbol mark and recycle system
are applied only to EU countries and not
applied to the countries in the other area of
the world.
Your product is designed and manufactured with
high quality materials and components which can be
recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed of
separately from your household waste.
Please dispose of this equipment at your local
Community waste collection or Recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
9 Technical data
9.1 General
Constructed from electropolished stainless steel
(Austenitic alloy stainless steel, corrosion and heat
resistant according to the following standards):
- UNI 6900-71: X 2 Cr Ni Mo 17 12
- AISI: 316
- DIN 17006: X 2 Cr Ni Mo 18 10
- N° WERKSTOFF: 1.4404
- AFNOR: Z2 CND 17-12
- BSI: 316 S 12
The screws utilised are in austenitic alloy stainless steel,
corrosion and heat resistant according to the following
standards:
- UNI 6900: X 5 Cr Ni Mo 1712
- AISI: 316
- ISO quality: A4
- Resistance class ISO: 80
Supplied with instruction manual, desiccant bag,
accessories for camera and lens mounting
UNI: Ente Nazionale Italiano di Unificazione, AISI: American Iron and
Standard Institute, DIN: Deutsche Industrie Normen, AFNOR: Association
Française de Normalisation, BSI: British Standard Institution, ISO:
International Organization for Standardization
