SPECIFICATIONS
Tuner
FM Frequency Range
87.5 MHz — 108.0 MHz (50 kHz space)
Usable Sensitivity (S/N = 26 dB)
0.71 μV/75 Ω
Quieting Sensitivity
(DIN S/N = 46 dB)
2.0 μV/75 Ω
Frequency Response (±3 dB)
30 Hz — 15 kHz
Signal-to-Noise Ratio (MONO)
64 dB
Stereo Separation (1 kHz)
40 dB
MW Frequency Range
531 kHz — 1 611 kHz (9 kHz space)
Usable Sensitivity (S/N = 20 dB)
28.2 μV
LW Frequency Range
153 kHz — 279 kHz (9 kHz space)
Usable Sensitivity (S/N = 20 dB)
50 μV
CD player
Laser Diode
GaAIAs
Digital Filter (D/A)
8 times over sampling
Spindle Speed
500 rpm — 200 rpm (CLV)
Wow & Flutter
Below measurable limit
Frequency Response (±1 dB)
20 Hz — 20 kHz
Total Harmonic Distortion (1 kHz)
0.01 %
Signal-to-Noise Ratio (1 kHz)
105 dB
Dynamic Range
90 dB
Channel Separation
85 dB
MP3 Decode
Compliant with MPEG-1/2 Audio Layer-3
WMA Decode
Compliant with Windows Media Audio
AAC Decode
AAC-LC “.m4a” files
USB
USB Standard
USB 1.1, USB 2.0 (Full speed)
File System
FAT12/ 16/ 32
Maximum Supply Current
DC 5 V
1 A
MP3 Decode
Compliant with MPEG-1/2 Audio Layer-3
WMA Decode
Compliant with Windows Media Audio
AAC Decode
AAC-LC “.m4a” files
WAV Decode
Linear-PCM
Audio
Maximum Output Power
50 W × 4
Output Power
(DIN 45324, +B = 14.4 V)
30 W × 4
Speaker Impedance
4 Ω — 8 Ω
Tone Action
Bass
200 Hz ±8 dB
Middle
2.5 kHz ±8 dB
Treble
12.5 kHz ±8 dB
Preout Level/Load (CD)
2 500 mV/10 kΩ
Preout Impedance
≤ 600 Ω
Auxiliary
Frequency Response (±3 dB)
20 Hz — 20 kHz
Input Maximum Voltage
1 200 mV
Input Impedance
30 kΩ
General
Operating Voltage
14.4 V (10.5 V — 16 V allowable)
Maximum Current Consumption
10 A
Operational Temperature Range
0°C — +40°C
Installation Size (W × H × D)
182 mm × 53 mm × 159 mm
Weight
1.2 kg
Subject to change without notice.
