AUX
Preparation:
Select [ON] for [BUILT-IN AUX]. ( 4)
Start listening
1 Connect a portable audio player
(commercially available).
2 Press B SRC to select AUX.
3 Turn on the portable audio player and
start playback.
Set the AUX name
While listening to a portable audio player
connected to the unit...
1 Press the volume knob to enter [FUNCTION].
2 Turn the volume knob to select [SYSTEM],
then press the knob.
3 Turn the volume knob to select [AUX NAME
SET], then press the knob.
4 Turn the volume knob to make a selection,
then press the knob.
AUX (default)/ DVD/ PORTABLE/ GAME/ VIDEO/ TV
5 Press and hold
to exit.
Auxiliary input jack
Portable audio
player
3.5 mm stereo mini plug with “L”
shaped connector (commercially
available)
AUDIO SETTINGS
While listening to any source...
1 Press the volume knob to enter [FUNCTION].
2 Turn the volume knob to select [AUDIO CONTROL], then press the knob.
3 Turn the volume knob to make a selection (see the following table), then press the knob.
Repeat
step 3 until the desired item is selected or activated.
4 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
Default: XX
SUB-W LEVEL –15 to +15 (0) Adjusts the subwoofer output level.
BASS LEVEL –8 to +8 (+6)
Adjusts the level to memorize for each source. (Before making an adjustment, select the
source you want to adjust.)
MID LEVEL –8 to +8 (+5)
TRE LEVEL –8 to +8 (0)
EQ PRO
BASS ADJUST BASS CTR FRQ 60/ 80/ 100/ 200HZ: Selects the center frequency.
BASS LEVEL –8 to +8 (+6): Adjusts the level.
BASS Q FACTOR 1.00/ 1.25/ 1.50/ 2.00: Adjusts the quality factor.
BASS EXTEND ON: Turns on the extended bass. ; OFF: Cancels.
MID ADJUST MID CTR FRQ 0.5/ 1.0/ 1.5/ 2.5KHZ: Selects the center frequency.
MID LEVEL –8 to +8 (+5): Adjusts the level.
MID Q FACTOR 0.75/ 1.00/ 1.25: Adjusts the quality factor.
TRE ADJUST TRE CTR FRQ 10.0/ 12.5/ 15.0/ 17.5KHZ: Selects the center frequency.
TRE LEVEL –8 to +8 (0): Adjusts the level.
PRESET EQ DRIVE EQ/ TOP40/ POWERFUL/ ROCK/ POPS/ EASY/ JAZZ/ NATURAL/ USER: Selects a preset equalizer
suitable to the music genre. (Select [USER] to use the customized bass, middle, and treble settings.)
[DRIVE EQ] is a preset equalizer that reduces noise from the road.
BASS BOOST LEVEL1 / LEVEL2/ LEVEL3: Selects your preferred bass boost level. ; OFF: Cancels.
LOUDNESS LEVEL1/ LEVEL2: Selects your preferred low and high frequencies boost to produce a well-balanced sound at
a low volume level. ; OFF: Cancels.
