SUBWOOFER SET ON: Turns on the subwoofer output. ;
OFF: Cancels.
LPF SUBWOOFER THROUGH: All signals are sent to the
subwoofer. ; 85HZ/ 120HZ/ 160HZ: Audio
signals with frequencies lower than 85 Hz/
120 Hz/ 160 Hz are sent to the subwoofer.
SUB-W PHASE REVERSE (180°)/ NORMAL (0°): Selects
the phase of the subwoofer output to be in
line with the speaker output for optimum
performance. (Selectable only if a setting
other than [THROUGH] is selected for
[LPF SUBWOOFER].)
HPF THROUGH: All signals are sent to the
speakers. ; 100HZ/ 120HZ/ 150HZ: Audio
signals with frequencies higher than
100 Hz/ 120 Hz/ 150 Hz are sent to the
speakers.
FADER R15 to F15 (0): Adjusts the rear and front
speaker output balance.
BALANCE L15 to R15 (0): Adjusts the left and right
speaker output balance.
VOLUME OFFSET
(Default: 0) –8 to +8 (for AUX) ; –8 to 0 (for other
sources): Presets the volume adjustment
level of each source. (Before adjustment,
select the source you want to adjust.)
SOUND RECNSTR
(Sound
reconstruction) ON: Creates realistic sound by
compensating the high-frequency
components and restoring the rise-time of
the waveform that are lost in audio data
compression. ; OFF: Cancels.
[SUB-W LEVEL]/ [LPF SUBWOOFER]/ [SUB-W PHASE] is
selectable only if [SUBWOOFER SET] is set to [ON].
DISPLAY SETTINGS MORE INFORMATION
1 Press the volume knob to enter [FUNCTION].
2 Turn the volume knob to select [DISPLAY],
then press the knob.
3 Turn the volume knob to make a selection
(see the following table), then press the
knob.
Repeat step 3 until the desired item is selected
or activated.
4 Press and hold to exit.
To return to the previous setting item or
hierarchy, press
.
Default: XX
COLOR SELECT VARIABLE SCAN/ COLOR 01 —
COLOR 24/ USER: Selects your preferred
key and display illumination color.
You can create your own color (when
[COLOR 01] — [COLOR 24] or [USER] is
selected). The color you have created can be
selected when you select [USER].
1 Press and hold the volume knob to enter
the detailed color adjustment.
2 Press S / T to select the color (R/
G/ B) to adjust.
3 Turn the volume knob to adjust the level
(0 — 9), then press the knob.
DIMMER ON: Dims the display and button
illumination. ; OFF: Illuminates according to
the [BRIGHTNESS] settings.
BRIGHTNESS 0 — 31: Selects your preferred brightness
level for display and button illumination.
TEXT SCROLL AUTO/ ONCE: Selects whether to scroll the
display information automatically, or scroll
only once. ; OFF: Cancels.
AUDIO SETTINGS
General
• This unit can only play the following CDs:
• Detailed information and notes about the playable
audio files are stated in an online manual on the
following web site:
www.kenwood.com/cs/ce/audiofile/
Playable files
• Playable audio file: MP3 (.mp3), WMA (.wma),
AAC (.m4a)
• Playable disc media: CD-R/CD-RW/CD-ROM
• Playable disc file format: ISO 9660 Level 1/2, Joliet,
Long file name.
• Playable USB device file system: FAT12, FAT16,
FAT32
Even when audio files comply with the standards
listed above, playback may be impossible depending
on the types or conditions of media or device.
Unplayable discs
• Discs that are not round.
• Discs with coloring on the recording surface or discs
that are dirty.
• Recordable/ReWritable discs that have not been
finalized.
• 8 cm CD. Attempting to insert using an adapter may
cause malfunction.
