12 | Quick Start Guide
Installing the trim plate/
Installation
Removing the Unit
Removing the trim plate
1
Engage the catch pins on the extraction key
(Accessory 3) and remove the two locks on the
lower level.
Lower the frame and pull it forward as shown in
the figure.
Accessory 3
Lock
Catch
⁄
• The frame can be removed from the top side in the
same manner.
2
When the lower level is removed, remove the upper
two locations.
Installing the trim plate
Attach Accessory 2 to the unit.
Accessory 2
Installation
Bend the tabs of the mounting sleeve
with a screwdriver or similar utensil
and attach it in place.
⁄
• Make sure that the unit is installed securely in
place. If the unit is unstable, it may malfunction (for
example, the sound may skip).
