Operating Specifications
•
Standard operating temperature: 32°F to 120°F (0°C to
49°C).
•
Humidity range: 10% to 93% non-condensing (indoor
products).
•
Strobe flash rate: 1 flash per second.
•
Nominal voltage: regulated 12 VDC/FWR or regulated 24
VDC/FWR. NOTE: Full Wave Rectified (FWR) voltage is a
non-regulated, time-varying power source that is used on
some power supply and panel outputs.
•
Operating voltage range: 8 V to 17.5 V (12 V nominal); or
16 V to 33 V (24 V nominal). NOTE: CHS products will
operate at 12 V nominal only for 15 cd and 15/75 cd.
•
Input terminal wire gauge: 12 to 18 AWG (3.31 to 0.821
mm²).
•
Chime/strobe dimensions (including lens): 5.6" H x 4.7"
W x 2.5" D (14.2 cm H x 11.9 cm W x 6.4 cm D).
•
Chime dimensions: 5.6" H x 4.7" W x 1.3" D (14.2 cm H x
11.9 cm W x 3.3 cm D).
Agency Listings and Approvals
The listings and approvals below apply to SpectrAlert Advance
Selectable Output Chimes and Chime/Strobes. In some cases,
certain modules may not be listed by certain approval agen-
cies, or listing may be in process. Consult factory for latest list-
ing status.
•
ULC Listed: file S4011.
•
FM approved.
Ordering Information
CHR: Chime, red.
CHW: Chime, white.
CHSR: Chime/strobe, red.
CHSW: Chime/strobe, white.
BBS-2: Backbox skirt, wall, red.
BBSW-2: Backbox skirt, wall white.
Current Draw, ULC Maximum (mA RMS)
Input, Pattern, dB Out
8 – 17.5 Volts
16 – 33 Volts
15 cd
15/75 cd
15 cd
15/75 cd
30 cd
75 cd
95 cd
110 cd
115 cd
DC, 1-Second Chime, HIGH
131
142
65
76
94
160
185
207
213
DC, 1-Second Chime, LOW
131
142
64
75
92
157
183
203
212
DC, 1/4-Second Chime, HIGH
129
142
66
75
95
159
184
205
212
DC, 1/4-Second Chime, LOW
129
142
64
74
91
155
181
204
211
DC, Temporal Chime, HIGH
125
142
64
74
91
156
181
205
211
DC, Temporal Chime, LOW
129
141
65
75
92
155
180
200
209
DC, 5-Second Whoop, HIGH
133
145
70
81
99
165
189
210
217
DC, 5-Second Whoop, LOW
130
143
66
77
95
160
186
206
214
DC, One-Time Chime
127
141
64
76
93
156
182
203
210
FWR, 1-Second Chime, HIGH
128
150
72
82
98
158
183
202
210
FWR, 1-Second Chime, LOW
127
150
71
81
97
157
182
202
210
FWR, 1/4-Second Chime, HIGH
129
149
72
82
99
160
183
203
211
FWR, 1/4-Second Chime, LOW
128
149
71
81
97
154
179
196
205
FWR, Temporal Chime, HIGH
128
148
71
81
97
157
179
199
206
FWR, Temporal Chime, LOW
125
147
71
81
97
156
180
200
206
FWR, 5-Second Whoop, HIGH
136
152
84
93
110
170
193
212
220
FWR, 5-Second Whoop, LOW
132
150
77
86
102
161
184
203
214
FWR, One-Time Chime
127
147
72
82
97
157
181
200
210
