1.1.5 Change Edits To – Good or Bad
This will set the value to be applied to the selected soundings. If ‘Bad’ is
selected, clicking the Apply button in the control panel will change the
beam flag for the selected soundings to ‘Bad’.
1.1.6 Attitude Correct
Checking this box will apply attitude corrections to the soundings displayed in the editing
windows.
1.1.7 XTF ping #
Checking this box will change the ping number display from a relative numbering scheme
starting a one to the actual ping numbers in the raw data file.
1.1.8 Side View
This checkbox controls the display of the Sweep Side View window (along-track display).
Closing the Side View window helps to speed things up when working with large data files
or on an old computer.
1.1.9 Navigation Controls
There are two methods for moving through the data file.
1. Near the bottom of the control panel are the following four buttons:
Go to the start of the line
Go backwards in file by the # of pings indicated in the Overlap field
Go forwards in file by the # of pings indicated in the Overlap field
Go to the end of the file
2. Below the navigation buttons is a slider bar which can be dragged to any point in the
data file. A real-time read out of the file ping number allows the users to drag the
slider bar to a specific location in the file.
