1.1 Monitors
The DVR can provide the follow output screens:
• Main This is used for full-screen or multi-screen live, play and configuration
• Aux
This is used for full-screen or multi-screen live and play
These output screens are displayed on the monitors with a priority depending on what types of monitor
are connected:
HDMI VGA Main Aux
- Connected VGA BNC
Connected -
HDMI BNC
Connected Connected HDMI BNC
- -
BNC n/a
Note that the HDMI and VGA monitors VGA Monitor must be connected prior to power-up so that they
are detected and given the correct usage.
1.1.1 VGA Monitor
A VGA monitor is recommended for most application for ease of interface and to benefit from high
resolution images. Supported resolutions are: 1920Ч1080, 1600Ч1200, 1280Ч1024, 1280Ч720 and
1024×768. The Vi-R4000 series allows units to be cascaded and to share a common VGA monitor
(and mouse). Refer to section Error! Reference source not found..
1.1.2 Low Resolution VGA Monitor
If you are using a VGA monitor with a resolution lower than the factory default (1280×1024), there is a
macro command to lower the resolution to 1024×768 so that the menu and images will be visible on
the monitor: Press and hold LIVE key and enter 9001, release LIVE key. Press and hold LIVE key
and enter 8000, release LIVE key.
1.1.3 HDMI / DVI Monitor
A HDMI or DVI Monitor may also be connected and is especially useful when used in conjunction with
a VGA monitor to provide dual independent high-resolution displays. Supported resolutions are:
1920Ч1080, 1600Ч1200, 1280Ч1024, 1280Ч720 and 1024×768.Note that a HDMI to DVI cable is
required to use a monitor with a DVI port.
1.1.4 BNC Monitor
A BNC monitor output is provided which may be used for Main or Aux displays.
