3.6 PTZ Control
3.6.1 Connection for dome control via menu or ethernet
In order to control domes using the mouse or remotely control domes via ethernet, a connection is
required on the back of the DVR between the green terminal block the dome(s):
Terminal Block Dome connection
PTZ + RS485+
PTZ - RS485-
3.6.2 RS485 Dome Protocols
If you want to control PTZ domes, protocol and baud rate is set in the menu to suit the dome(s).
Menu>Camera>PTZ
Select PTZ mode either using pressing the PTZ key or right-clicking the mouse on a live camera
image and pressing the PTZ icon.The dome may now be controlled by the mouse.
3.6.3 RS485 Dome Control via Ethernet
If you want to control PTZ domes via a network, whether locally or via broadband, this is achieved
using mouse control as above except from the remote viewing software.
