4.1 Live Viewing
4.1.1 Full screen
To select full screen camera images:
• Enter the camera number using the number keys: 1,2,3,4,5,6,7,8,9,0
• Pressing
the à and Ä keys to step through cameras
• Right click on mouse and select Main or Aux monitor and required camera.
4.1.2 Multi-Screen
To select multi-screen camera images:
• Press the SCREEN key to get the format you require. Use à and Ä for different camera
groups in multi-screens.
• Right click on mouse and select Main or Aux monitor and required screen format
4.1.3 Auto-Switching
If a dwell time has been set in the Configuration>Live View menu, pressing SEL will start camera
switching on the main monitor.
To stop swiitching:
Left click on mouse and select Stop Auto-Switch
4.1.4 Main or Aux Monitor Selection
Press the MAIN/AUX key then SELECT to switch between main and aux monitors so that camera can
be selected.
Note: Take care if the other monitor isn’t attached or visible to you, as you will lose sight of your
cursor. If this happens, just press MAIN/AUX key then SELECT again and control will return to your
monitor.
4.1.5 Screen Warning Symbols
The following symbols may appear on the screen for each camera.
To find what has caused the alert:
• Press
HELP key to go to menu path: Menu>Maintenance->System Info
• Look at Camera, Record, Alarm, Network and HDD tabs and check for errors
• Select
Log Information
Click on Search (change date and Major Type and Minor Type to narrow down the events as
required)
4.1.5.1 Yellow Triangle
The yellow triangle is an alert cause by either:
