- 5 -
The lens motors will then move to the position at which the controllers are set. Note: If
you turn off power to the receiver, it will store the calibration set in the last use. As
long as you don’t move the motors or lens, the calibration will be valid. If you have
to move the motors and lens from their last position, recalibrate.
Basic Operation
The TOC has a touch screen that will allow for easy menu navigation. Most
operation will be done from this screen.
To reset the TOC parameters to their defaults, select “System” from the
home menu. Then select “Reset All”. It will then ask you to confirm. Select “OK”,
and then all parameters will be set to default. This only applies to lens/motors
limits, and motors speed/smoothing settings. Lens calibration is not affected by the
system reset.
The touch screen allows for easy adjustments and menu navigation. In the rare event that
the touch screen becomes unusable, there are five buttons on the top of the controller next
to the antenna (see below) that can be used as backup for navigation.
Return to Home screen
Enter Menu Up
Menu Down
Power on/off
