CONA
®
S - Ball float steam traps
7.5 Tightening torques
(refer to Fig. 1 page 4 - Fig. 6 page 11)
8.0 Troubleshooting
In the event of malfunction or faulty operating performance check that the installation and
adjustment work has been carried out and completed in accordance with these Operating
Instructions.
If malfunctions cannot be eliminate with the help of the following table
“9.0 Troubleshooting table”, the supplier or manufacturer should be consulted.
Pos. CONA S PN16
Torque (Nm)
DN15-20 DN25 DN32-50
24 Controller 60 60 100
24.8 Hex. nut M4 / M4 / M6 5 5 10
50 Plug 50 50 50
27 Cheese head screw M10 / M12 / M16 15 25 50
51 Manual air vent valve 50 50 50
51.1 Pressure screw 30 30 30
46 Blow down valve 50 50 50
46.1 Pressure screw 30 30 30
52 Union for pressure compension line 50 50 50
Pos. CONA S PN40
Torque (Nm)
DN15-20 DN25 DN32-50
24 Controller 60 60 100
24.8 Hex. nut M4 / M6 5 5 10
28 Hex. nut M12 / M12 / M16 25 30 60
50 Plug 70 70 70
51 Manual air vent valve 70 70 70
51.1 Pressure screw 30 30 30
46 Blow down valve 70 70 70
46.1 Pressure screw 30 30 30
52 Union for pressure compension line 70 70 70
-
ATTENTION !
- It is essential that the safety regulations are observed when identifying faults.
