Acer 5000 - Manual (Page 57)

48 Chapter 1
Rated voltage for 100Vac or 240Vac input AC
voltage for 100Vac or 240Vac input AC
voltage
Input voltage range from 90Vac to 264Vac from 90Vac to 265Vac
Rated frequency for 50Hz or 60Hz for 50Hz or 60Hz
Frequency range from 47Hz to 63Hz from 47Hz to 63Hz
Steady AC current less than 1.5A rms at 100Vac
input and maximum load less than 1.5A rms at 100Vac
input and maximum load
Output feature
Rated voltage
19V 19V
Voltage range 18.05V to 20V from 18.2V to 19.8V
Rated power 90 W 90 W
Output ripple and noise less than 300mVp-p less than 300mVp-p
Turn on delay time within two seconds at 115 Vac
input voltage within two seconds at 115 Vac
input voltage
Temperature Operating: 0 to 40 o C
Non-operating: -31 to 60 o C
Operating: 0 to 40 o C
Non-operating: -31 to 60 o C
Item Specification
