LIMITED WARRANTY
The Company warrants the products it manufactures against defects in materials and workmanship for a
period limited to two years from the date of shipment, provided the products have been stored, handled,
installed, and used under proper conditions. The Company’s liability under this limited warranty shall
extend only to the repair or replacement of a defective product, at The Company’s option. The Company
disclaims all liability for any affirmation, promise or representation with respect to the products.
The customer agrees to hold Red Lion Controls harmless from, defend, and indemnify RLC against
damages, claims, and expenses arising out of subsequent sales of RLC products or products containing
components manufactured by RLC and based upon personal injuries, deaths, property damage, lost profits,
and other matters which Buyer, its employees, or sub-contractors are or may be to any extent liable,
including without limitation penalties imposed by the Consumer Product Safety Act (P.L. 92-573) and
liability imposed upon any person pursuant to the Magnuson-Moss Warranty Act (P.L. 93-637), as now in
effect or as amended hereafter.
No warranties expressed or implied are created with respect to The Company’s products except those
expressly contained herein. The Customer acknowledges the disclaimers and limitations contained herein
and relies on no other warranties or affirmations.
Do not dispose of unit in trash - Recycle
ORDERING INFORMATION
MODEL NO. DIN SIZE
MAIN CONTROL
OUTPUT 1
SECONDARY
CONTROL OUTPUT 2
USER INPUT(S) RS 485 100 to 240 VAC
PXU
1/16
Relay - - - PXU10020
Relay Relay 2 Yes PXU11A20
Logic/SSR - - - PXU20020
Logic/SSR Relay 2 Yes PXU21A20
4-20 mA - - - PXU30020
4-20 mA Relay 2 Yes PXU31A20
1/8
(vertical)
Relay - - - PXU10030
Relay Relay 2 Yes PXU11A30
Logic/SSR - - - PXU20030
Logic/SSR Relay 2 Yes PXU21A30
4-20 mA Relay 2 Yes PXU31A30
1/4
Relay Relay 2 Yes PXU11A50
4-20 mA Relay 2 Yes PXU31A50
Only stocked part numbers are listed. Contact factory for availability of non-stock models.
In order to program the unit using Crimson, the unit must be purchased with the 485 option.
ACCESSORIES
MODEL NO. DESCRIPTION PART NUMBERS
RLY
External SSR Power Unit (for Logic/SSR models) RLY50000
25 A Single Phase Din Rail Mount Solid State Relay RLY60000
40 A Single Phase Din Rail Mount Solid State Relay RLY6A000
Three Phase Din Rail Mount Solid State Relay RLY70000
