3
CSINV8 SPECIFICATIONS
21. INPUTS:
Channels: 8 single-ended
Ranges: 0-10 VDC or ±10 VDC
Effective Resolution: Full 16-bit
Programmable Scaling: ±30,000
Linearizer: 100 Points (CSINV8L0 only)
Sample Time: 50 msec - 400 msec, depending on number of enabled inputs.
ENABLED
INPUTS
SCAN TIME
(READING RATE)
1 50 msec (20 Hz)
2 100 msec (10 Hz)
3 150 msec (6.7 Hz)
4 200 msec (5 Hz)
5 250 msec (4 Hz)
6 300 msec (3.3 Hz)
7 350 msec (2.9 Hz)
8 400 msec (2.5 Hz)
Common Mode Rejection: >110 dB, 50/60 Hz
Normal Mode Rejection: >90 dB, 50/60 Hz
Step Response Time: One scan time (to within 99% of final value)
Input Impedance: 10 M

Max. Continuous Overload: 50 V
22. ACCURACY: ±0.1% of span
23. INPUT FAULT RESPONSE: Upscale Drive, Input Fault Alarm bit set
high, ALM LED illuminates below -10.4 VDC and above +10.4 VDC.
CSINI8 SPECIFICATIONS
18. INPUTS:
Channels: 8 single-ended
Ranges: 0-20 mA or 4-20 mA
Effective Resolution: Full 16-bit
Programmable Scaling: ±30,000
Linearizer: 100 Points (CSINI8L0 only)
Sample Time: 50 msec - 400 msec, depending on number of enabled inputs.
ENABLED
INPUTS
SCAN TIME
(READING RATE)
1 50 msec (20 Hz)
2 100 msec (10 Hz)
3 150 msec (6.7 Hz)
4 200 msec (5 Hz)
5 250 msec (4 Hz)
6 300 msec (3.3 Hz)
7 350 msec (2.9 Hz)
8 400 msec (2.5 Hz)
Common Mode Rejection: >110 dB, 50/60 Hz
Normal Mode Rejection: >90 dB, 50/60 Hz
Step Response Time: One scan time (to within 99% of final value)
Input Impedance: 10

Max. Continuous Overload: 100 mA
19. ACCURACY: ±0.1% of span
20. INPUT FAULT RESPONSE: Upscale Drive, Input Fault Alarm bit set
high, ALM LED illuminates below -3 mA, and above 23 mA for 0-20 mA
range; below +3 mA and above 23 mA for 4-20 mA signals.
CSRTD6 SPECIFICATIONS
15. RTD INPUTS:
Channels: 6 single-ended
Effective Resolution: Full 16-bit
Sample Time: 67 msec - 400 msec, depending on enabled inputs.
ENABLED
INPUTS
SCAN TIME
(READING RATE)
1 67 msec (14.9 Hz)
2 133 msec (7.5 Hz)
3 200 msec (5 Hz)
4 267 msec (3.8 Hz)
5 333 msec (3 Hz)
6 400 msec (2.5 Hz)
Common Mode Rejection: >110 dB, 50/60 Hz
Normal Mode Rejection: >90 dB, 50/60 Hz
Temperature Coefficient: 0.01%/°C
Step Response Time: One scan time (to within 99% of final value)
Type: 2 or 3 wire
Excitation: 150 μA
Lead Resistance: 15  Max
Resolution: 0.1°
Slope & Offset: Provides sensor error correction
16. TEMPERATURE INDICATION ACCURACY: Includes NIST conformity,
A/D conversion errors, temperature coefficient and linearization conformity at
23 °C after 20 minute warm up.
17. PROBE BREAK RESPONSE: If channel is enabled: upscale drive, Input
Fault Alarm bit set high, ALM LED illuminates.
TYPE INPUT TYPE RANGE
385 ± (0.2% of span) ± (0.1% of span)
-200 to +600 °C
-328 to +1100 °F
392 ± (0.2% of span) ± (0.1% of span)
-200 to +600 °C
-328 to +1100 °F
672
Ohms Linear resistance
± (0.2% of span) ± (0.1% of span)
-80 to +215 °C
-112 to +419 °F
± (0.2% of span) ± (0.1% of span) 0

to 300

428
50

copper,
Alpha = .00428
± (1.2% of span) ± (0.6% of span)
-50 to +200 °C
-58 to +392 °F
120

nickel,
Alpha = .00672
100

platinum,
Alpha = .003919
100

platinum,
Alpha = .00385
ACCURACY
0 TO 50°C
ACCURACY
18 TO 28°C
