Ronbow 600823 - Manual

Rev. Oct, 2013 ronbow.com INStALLAtION GUIDe
INStALLAtION SHeet ACCESSORIES MODEL: 600823
601224
602523
LED MIRROR
MATERIALS NEEDED:
PHILIP SCREWDRIVER
LEVELING TOOL
DRILL
MATERIAL PROVIDED:
(2)WOOD SCREWS
(2)ANCHORS
Circuit Breaker
ALL wIRINg ShOuLD bE DONE by A quALIfIED LIcENSED ELEcTRIcIAN.
wARNINg: To reduce the risk of electrical shock, shut off power before wiring the cabinet.
cAuTION: Requires 120V 20AMP circuit.
cAuTION: The LED mirror must be wired to a 20AMP GFI (ground fault interrupter) circuit breaker when used in bathrooms
and all other locations required by the national electric code.
Wall Terminal
Black Black
White White
Ground
20AMP CFI
figure 1. STEP 1: Determine the ideal location of your new
LED mirror. Make sure mirror has enough clearance
from faucet and ceiling.
See Figure 1.
Minimum to Faucet
Minimum to Ceiling
1”
1”
