Ronbow 350301-AB - Manual

Installation Sheet
www.ronbow.com
Step 1 :
Step 3 :
Ronbow Corporation, All Rights Reserved.
Stone Vessel
Model: 350301-AB
350418-CW
Step 2 :
Step 4 :
Position countertop drain opening to
ensure clearance between the lavatory,
faucet & backsplash. Cut 1-3/4” hole
for drain in countertop
See Figure 1.
Place a generous portion of plumbers’
putty under drain cap and insert
whole drain body inside the bowl and
through the countertop.
(There may be a small beveled rubber washer
packaged with your drain, please discard this
and use plumbers’ putty instead)
See Figure 2.
From under the drain, insert the thick
rubber washer and screw on and
tighten the metal nut. Remove excess
plumbers’ putty
See Figure 3.
Attach p-trap to tailpiece.
Above Counter Sinks
Figure 1.
Drain
Metal Nut
Tailpiece
P-trap
Thick rubber
washer
Figure 3.
Note : For Stone Sinks without overflow
Metal Nut
Thick rubber
washer
Tailpiece
Figure 2.
Drain Cap
