RocketRAID 230x Driver and Software Installation

Write-back - when the write-back setting is selected, all write requests sent to

the array are cached. This will result in higher performance, but data loss may

occur in case of a power failure.

Write-through - when the write-through setting is selected, all write requests

sent to the array are passed directly to the disks. However, subsequent reads

may still be completed from the cache if appropriate.

Select which disks are to be used to create the array. Highlight the desired disk

from the left-side of the interface (available disks), then click on the

button

to move the disk to the right side of the interface (selected disks). Disks must be

selected one a time.

If you wish to remove a selected disk, highlight it from the selected disk section,

and use the

button to move it to the available disk section.

Note: The selection sequence is important - the order in which the disks are

selected will determine the disk sequence of the array.

Select the capacity - the RocketRAID host adapter can create arrays between

partitions on various disks. It is not limited to physical hard disk drives. As a

result of this feature, you have the option of assigning a physical disk to multiple

RAID arrays.

Press Enter to use the default value (the maximum capacity for the array), or

specify the desired value using the keyboard, and press Enter to confirm this

selection. Then, click the Finish button.

Note: If you have specified an initialization option, the initialization process will start

automatically. A progress bar will be displayed towards the bottom of the interface

window, and will indicate % completion, and provide an estimate of the time needed

to complete the initialization procedure.
