31
3. SETUP MENU
continued …
Highlighting ‘f. DVD1’ in menu 6 then pressing SELECT displays this menu – the other submenus are similar:
Rename:
The factory assigned Source names that appear on the Front Panel Display and the On-Screen Display can
be changed to another name, up to six characters long. The following characters are available:
A, B, C....Z, a, b, c....z, blank, dash (–), period (.), slash (/), 0, 1, 2....9, colon (:).
After highlighting the RENAME line, press SELECT and use the buttons to move from character to
character, then use the buttons or rotate the Master Control Knob to change the character. It is also
possible to rename ‘ZONE2’, ‘ZONE3’, and ‘RECORD’ – see section 3.10.
When a Source is renamed, the new name appears next to the factory name in menu 6 and menu 7 root
menus and at the top of the renamed Source’s submenu.
Example: Rename AUX to ‘GAME’.
• Enter the Setup Menu. Go to ‘6. SOURCE SETUP’ and press SELECT.
• Press the button until you reach ‘q. AUX’ and press SELECT.
• ‘a. RENAME: AUX’ will be highlighted in red.
• Press SELECT. The first character ‘A’ will be highlighted in red.
• Use the Master Control Knob or the buttons to change characters. Change the first one to ‘G’.
• Press the button to move to the next character. Change it to ‘A’.
• Use the buttons to move to each remaining character. Change to ‘M’ and ‘E’.
• Press BACK to leave the submenu and return to the main menu.
Video Output Configuration (applies to MAIN only):
Choose between configurations 1 to 4 as set in menu 1, or Last Used. When Last Used is selected, the video
configuration will be the same as the one that the previously selected source was using.
6f. DVD1 SOURCE SETUP
a. RENAME: DVD1
b. VID OUT CNFG: 1
c. SCALER INPUT: HDMI1
d. COMPONENT IN: 1
e. S-VIDEO IN: DVD
f. COMPOSITE IN: DVD
g.AUDIO IN: Dig HDMI
h.AUTO DIG: No
i.HDMI MAP: Auto
j. MUTING: Med
k.EQ LF +0.0dB HF +0.0dB
l. BASS MGR: Auto-LFE
m. LIP-SYNC: 0.0 ms
n.HDMI REPEATER: Yes
