2. CONNECTIONS
continued …
Example 2: Video Recorder to AVM 50
DVD
SATELLITE
VCR
EJECT
CD Player
EJECT
Track 1
PO WER
120V 60Hz
MAX
E X PA N S I O N P O R T SHOCK HAZARD
DO NOT OPEN.
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
M A I N A U D I O - O U T ( B A L A N C E D )
SUB 2
M A I N A U D I O - O U T
AUDIO
OUT
L
R
AUDIO
IN
For ZONE2, ZONE3, and
REC, in most cases you
must use the same input
type as the output type.
If MAIN uses a different
input connection, all you
need to do is add these
connections for ZONE2,
ZONE3, and REC.
VIDEO
OUT
VIDEO
IN
L
R
