3
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 883945 1 White Front Panel Assembly
(includes illus. nos. 1, 8, and 9)
883946 1 Bisque Front Panel Assembly
(includes illus. nos. 1, 8, and 9)
2 150517 10 #10-16 x 1-1/4” Hex Head TEK Screw
3 800453 2 Main Door Switch Assembly
4 150311 2 #10-16 x 3/4” TEK Screw
5 854117 1 Kick Plate
6 150311 2 #10-16 x 3/4” Head TEK Screw
7 150309 8 #10-16 x 1/2” Hex Head TEK Screw
8 881987 2 Friction Door Latch Kit
(includes illus. nos. 8 and 9)
9 154215 4 5/32 x 1/4” Rivet
10 102317 10 Foam Block
11 116329 1 Upper Front Panel Insulation
12 116330 1 Lower Front Panel Insulation
Front Panel Assembly
