11
Telephone: (508) 678-9000 Fax: (508) 678-9447
Bottom Locking Lint Basket Assembly
Illus. No. Part No. Qty. Description
1 115904 1 Lint Basket Felt
2 154210 5 5/32” x 3/16” Pop Rivet
3 160140 1 Key ONLY for XX4451
4 882797 1 Bottom Locking Lint Basket Assembly with Lock (black)
(includes illus. nos. 1 through 6)
882796 1 Bottom Locking Lint Basket Assembly with No Lock (black)
(includes illus. nos. 1, 2, 4, and 6)
5 160038 1 Lint Basket Lock with Cam (no key)
6 117604 4 1/8” x 3/8” Neoprene Sponge Tape (sold by the foot)
