Bottom Burner Box Assembly
Illus. No. Part No. Qty. Description
1 –––––* 1 Bottom Rear Electric Panel Assembly
2 152002 2 1/4-20 Hex Nut
3 153007 2 1/4” Split Lock Washer
4 142715 1 1/2” x 2” Nipple
5 128915 1 Ignitor with Flame Probe
6 128927 1 Gas Valve
7 150301 6 #8-18 x 7/16” Phillips Pan Head TEK Screw
8 354049 1 Gas Valve Mounting Bracket
9 141228 1 2-Port Manifold
10 142619 1 1/2” N.P.T. End Cap
11 360109 1 Gas Line Hole Cover
12 143118 1 1/2” x 1/2” x 60” Stainless Steel Flex Hose
13 142506 1 1/2” x 1/2” Street Elbow
14 153018 4 1/4” Flat Washer
15 150512 2 1/4-20 x 1/2” Hex Head Machine Bolt
16 130400 1 Temperature Sensor
17 128919 1 36” Ignition Cable
18 354162 1 Direct Spark Ignition (DSI) Module Mounting Panel
19 801048 1 Direct Spark Ignition (DSI) Johnson Control Module with Label
20 140844 2 Burner Orifice
21 142820 1 1/2” x 12” x 1/2” Tee
22 142700 1 1/2” Close Nipple
23 360146 11 Burner Manifold Bracket
24 354261 3 Flexible Gas Line Bracket
25 150299 2 #10 x 1” Hex Washer Screw
26 150309 17 #10-16 x 1/2” Hex Head TEK Screw
27 121300 1 Open/Closed Bushing
28 121400 1 7/8” Universal Bushing
29 152013 2 #6-32 Hex Nut
30 153562 2 #6-32 x 3/4” Black Self-Tapping Clinching Stud
31 141141 2 Burner Tube
32 860029 1 Burner Box
33 120910 2 Green Ground Screw
* Refer to Bottom Rear Electrical Panel 120-240v 1ø 50/60 Hz on page 24.
