Illus. No. Part No. Qty. Description
1 –––––* 1 Top Rear Electric Panel Assembly
2 152002 2 1/4-20 Hex Nut
3 153007 2 1/4” Split Lock Washer
4 354163 1 Pipe Bracket
5 142505 1 3/4” x 1/2” x 1/2” Tee
6 360146 1 Burner Manifold Bracket
7 128915 1 Ignitor with Flame Probe
8 354049 1 Gas Valve Mounting Bracket
9 150301 6 #8-18 x 7/16” Phillips Pan Head TEK Screw
10 140844 2 Burner Orifice
11 128927 1 Gas Valve
12 153018 4 1/4” Flat Washer
13 150512 2 1/4-20 x 1/2” Hex Head Machine Bolt
14 130400 1 Temperature Sensor
15 128919 1 36” Ignition Cable
16 354162 1 Direct Spark Ignition (DSI) Module Mounting Panel
17 801048 1 Direct Spark Ignition (DSI) Johnson Control Module
18 142710 1 3/4” x 4” Black Nipple
19 142700 1 1/2” Close Nipple
20 121400 1 7/8” Universal Bushing
21 150309 12 #10-16 x 1/2” Hex Head TEK Screw
22 150299 2 #10 x 1” Hex Washer TEK Screw
23 121300 1 Open/Closed Bushing
24 153562 2 #6-32 x 3/4” Black Self-Clinching Stud
25 152013 2 #6-32 Hex Nut
26 141228 1 2 Port Manifold
27 860029 1 Burner Box
28 142601 1 3/4” Black Union
29 141141 2 Burner Tube
30 120910 2 Green Ground Screw
* Refer to Top Rear Electrical Panel 120v 1ø 50/60 Hz on page 23.
Top Burner Box Assembly
