American Dryer Corp. Phase 7 AD-360X2RD - Manual (Page 31)

29
Telephone: (508) 678-9000 Fax: (508) 678-9447
Wrapper Assembly and Gasket
Illus. No. Part No. Qty. Description
1 102310 4 Wrapper Gasket (sold by the foot)
401010 1 3M Mastic
2 860045 1 Left Wrapper Assembly
3 860044 1 Right Wrapper Assembly
4 860069 1 Top and Bottom Temperature Sensor Assembly
5 360149 1 60º Spray Nozzle Mount
6 852319 1 Axial Sensor Probe Assembly
7 354243 1 Inner Back Cover Plate
8 360155 1 Left Side Air Blockage Plate
9 360153 1 Right Side Air Blockage Plate
