9
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 154210 40 5/32” x 3/16” Pop Rivet
2 354217 1 Spacer Plate
3 153048 1 Inner Friction Teflon ® Pad
4 116332 1 Felt Collar
5 882765 1 One Arm Basket (tumbler) Support Assembly
(includes illus. nos. 2, 3, and 5)
6 882766 1 Basket (tumbler) Assembly for One Arm Basket (tumbler) Support
(includes illus. nos. 1, 4, and 9)
882990 1 One Arm Basket (tumbler) and Support Assembly Complete
(includes illus. nos. 1 through 7 and 9)
7 154210 6 5/32” x 3/16” Pop Rivet
8 100191 1 12 Rib 105” Long (J) High Temperature Belt
9 115992 1 Inner Ring Felt Collar
401010 1 #847 Adhesive for Felt Collar (5 oz. tube)
Basket (Tumbler)/Support Assemblies
