Specifications
48 900-0020-01-00 Rev B
Table 12 GS8048 Inverter Settings
Field Item Default Minimum Maximum
Aux Mode Vent Fan
Load Shed, Gen Alert, Fault, Vent Fan, Cool Fan,
DC Divert, IEEE, Source Status, AC Divert
(Load Shed) ON: Batt > 56 Vdc 40 Vdc 72 Vdc
(Load Shed ON) Delay 30 Secs 6 Secs 1500 Secs
(Load Shed) OFF: Batt < 56 Vdc 48 Vdc 72 Vdc
(Load Shed OFF) Delay 18 Secs 6 Secs 1500 Secs
(Gen Alert) ON: Batt < 44 Vdc 40 Vdc 56 Vdc
(Gen Alert ON) Delay 30 Secs 6 Secs 1500 Secs
(Gen Alert) OFF: Batt > 56 Vdc 48 Vdc 72 Vdc
(Gen Alert OFF) Delay 30 Secs 6 Secs 1500 Secs
(Vent Fan) ON: Batt > 56 Vdc 48 Vdc 72 Vdc
(Vent Fan) Off Delay 18 Secs 6 Secs 1500 Secs
(DC Divert) ON: Batt > 56 Vdc 48 Vdc 72 Vdc
(DC Divert ON) Delay 30 Secs 6 Secs 1500 Secs
(DC Divert) OFF: Batt < 44 Vdc 40 Vdc 56 Vdc
(DC Divert OFF) Delay 30 Secs 6 Secs 1500 Secs
(AC Divert) ON: Batt > 56 Vdc 48 Vdc 72 Vdc
(AC Divert ON) Delay 30 Secs 6 Secs 1500 Secs
(AC Divert) OFF: Batt < 44 Vdc 40 vdc 56 Vdc
(AC Divert OFF) Delay 30 Secs 6 Secs 1500 Secs
Auxiliary
Relay
Aux Control Off Off, Auto or On
Aux Mode Gen Alert
Load Shed, Gen Alert, Fault, Vent Fan, Cool Fan,
DC Divert, IEEE, Source Status, AC Divert
(Load Shed) ON: Batt > 56 Vdc 40 Vdc 72 Vdc
(Load Shed ON) Delay 30 Secs 6 Secs 1500 Secs
(Load Shed) OFF: Batt < 56 Vdc 48 Vdc 72 Vdc
(Load Shed OFF) Delay 18 Secs 6 Secs 1500 Secs
(Gen Alert) ON: Batt < 44 Vdc 40 Vdc 56 Vdc
(Gen Alert ON) Delay 30 Secs 6 Secs 1500 Secs
(Gen Alert) OFF: Batt > 56 Vdc 48 Vdc 72 Vdc
(Gen Alert OFF) Delay 30 Secs 6 Secs 1500 Secs
(Vent Fan) ON: Batt > 56 Vdc 48 Vdc 72 Vdc
(Vent Fan) Off Delay 18 Secs 6 Secs 1500 Secs
(DC Divert) ON: Batt > 56 Vdc 48 Vdc 72 Vdc
(DC Divert ON) Delay 30 Secs 6 Secs 1500 Secs
(DC Divert) OFF: Batt < 44 Vdc 40 Vdc 56 Vdc
(DC Divert OFF) Delay 30 Secs 6 Secs 1500 Secs
(AC Divert) ON: Batt > 56 Vdc 48 Vdc 72 Vdc
(AC Divert ON) Delay 30 Secs 6 Secs 1500 Secs
(AC Divert) OFF: Batt < 44 Vdc 40 vdc 56 Vdc
(AC Divert OFF) Delay 30 Secs 6 Secs 1500 Secs
Inverter Stacking Stack Mode Master Master, Slave
Power Save
(in Stacking Menu)
Master Power Save Level 0 0 31
Slave Power Save Level 1 1 31
Grid-Tie Sell
Grid-Tie Enable Y Y or N
Sell Voltage 52 Vdc 40 Vdc 60 Vdc
Grid-Tie Window IEEE IEEE or user
Calibrate
Input Voltage 0 -7 7
Output Voltage 0 -7 7
Battery Voltage 0 -0.8 0.8
