Troubleshooting
900-0020-01-00 Rev B 41
Warning Messages
A Warning message is caused by a non-critical fault. When this occurs, the unit will not shut down, but
the MATE3 system display will show an Event and a specific Warning message. This screen is viewed
using the MATE3 Home screen’s soft keys. (See the MATE3 manual for more instructions.) One or
more messages will display
Y (yes). If a message says N (no), it is not the cause of the warning.
NOTE: The Radian series has no external indicators and requires the MATE3 system display to identify
a Warning.
Some warnings can become errors if left unattended. Frequency and voltage warnings are meant to
warn of a problematic AC source. Often the inverter will disconnect from the source. This will occur if
the condition lasts longer than the inverter’s transfer delay settings. If the inverter disconnects, the
warning will display as long as the source is present, accompanied by a Disconnect message. (See
next page.)
Warning screens can only display warnings; they cannot clear them. The way to correct the fault may
be obvious from the message.
Table 5 Warning Troubleshooting
Message Definition Possible Remedy
AC Freq Too High The AC source is above the upper acceptable
frequency limit (66 Hz) and prevents
connection.
Check the AC source. If it is a generator, reduce
its speed.
AC Freq Too Low The AC source is below the lower acceptable
frequency limit (54 Hz) and prevents
connection.
Check the AC source. If it is a generator, increase
its speed.
Voltage Too High The AC source is above the upper acceptable
voltage limit on either L1 or L2 (132 Vac
default setting) and prevents connection.
Check the AC source. The inverter’s acceptance
range is adjustable.
NOTE: Adjusting the range may accommodate a
problematic AC source, but it will not fix it.
Voltage Too Low The AC source is below the lower acceptable
voltage limit on either L1 or L2 (108 Vac
default setting) and prevents connection.
Check the AC source. Check the AC wiring. The
inverter’s acceptance range is adjustable.
NOTE: Adjusting the range may accommodate a
problematic AC source, but it will not fix it.
Input Amps > Max AC loads are drawing more current from the
AC source than allowed by the input setting.
Check the loads. Oversized loads can open circuit
breakers. If they exceed the inverter’s transfer
relay size, the relay can be damaged.
This issue is usually the result of a poorly-sized
load, as opposed to a wiring problem.
Temp Sensor Bad An internal inverter temperature sensor may
be malfunctioning. One of the three internal
sensor meters may give an unusual reading.
In the MATE3, the three readings are labeled
Transformer, Output FETs, and Capacitors.
These values are given in degrees Celsius. See
next page.
Comm Fault The inverter has suffered an internal
communication failure.
Unit still functions, but may require repair.
Contact OutBack Technical Support (see inside
front cover of this manual).
