GReddy AIR INTAKE SYSTEMS: Mitsubishi Lancer GTS 2009-12 - Manual (Page 4)

Refer to Figure A for step 1
Step 1: Remove the air inlet assembly from the vehicle 1 . Disconnect the wiring harness from the
Mass Air Sensor (MAS) 2 . Remove the crankcase breather hose and plastic elbow from the
air intake tube 3 . Loosen the clamps securing the air intake tube 4 and remove the air
intake tube from the vehicle. Release the clips (2) 5 securing the airbox cover. Remove the
airbox cover 6 and filter element. Remove the MAS from the stock intake tube.
REMOVAL
Page 4
1
2
3 4
4
5
6
Figure A
