NOTE: Before beginning you must first measure the width of your front end from LEFT outer tie rod end zerk to the RIGHT outer
tie rod end zerk to determine the overall width of your front end. Write dimension here for further reference


Parts Inventory

PG 2


Section 1 Original System Removal

A. Original Column & Wheel Removal

PG 3

B. Steering Box & Linkage Removal

PG 3



Section 2 Installation of Flaming River Column

A. Installation of New Flaming River Tilt Column

PG 3-4

B. Installation of original wheel

PG 4-5

C. Installation of aftermarket wheel

PG 5-6

D.

Connecting

Electrical

System

PG

6


Section 3 Installation of the Flaming River Rack & Cradle

A.

Installation of Manual Rack & Pinion Cradle

PG 7

B.

Installation of Manual Rack & Pinion

Universal Joint System

PG 8

C.

Installation of Power Rack & Pinion Assembly

PG 9

D.

Installation of Power Rack & Pinion Universal

Joint System

PG 9-10

D.

Installation of Power Steering Pump

PG 10


Section 5 Bleeding System

A.

Bleeding the power steering

PG 11


Torque Specs

PG 11


Note: For safety disconnect battery cables and ensure that vehicle is properly supported by jack stands.

Note: 65-66 Mustangs with V8 and power assist need to replace outer tie rods using manual V8 outer tie rod end.

We recommend a professional alignment to set the proper alignment settings.

We recommend that you always install new outer tie rod ends when installing this kit.

Note:

****

The use of Flaming River Headers maybe necessary with use of the Power Rack and Pinion System

. ****

Note: Flaming River Recommends that you use Dextron or high grade power steering fluid.

Warranty Disclaimer

All parts are sold without any express or implied warranty of merchantability as to fitness for the intended purpose. Flaming River
Industries, Inc. disclaims all liability for any damage or personal injury which may arise or result from the sale, installation or use of
any products. The installation of the products may adversely impact a manufacturer’s warranty with respect to certain vehicles and
other manufactured goods. It is the customer’s responsibility to select appropriate parts for the application. The disclaimer is
limited only by applicable state laws. Flaming River recommends using qualified chassis specialists for installation of all steering
related components. Flaming River will repair or replace any product found to be defective in material or workmanship. Improper
installation, abuse, racing and or modification void warranty. Flaming River is not responsible for any labor costs associated with
any warranty.
