Testing Transmission Pressure or
Engine Oil Pressure:
CAUTION: Always avoid contact with hot transmission fluid
and motor oil. Hot fluids can cause serious burns.
WARNING: Do not spill or allow hot fluids to leak onto hot
vehicle surfaces. Hot fluids in contact with hot surfaces
can cause fires, resulting in serious damage or injury.
1. Always refer to the manufacturer’s vehicle service or repair manual for
specific information including: diagnostic test procedures, fluid levels,
operating temperatures, and pressure specifications.
2. Select the proper gauge for the anticipated pressure range. If pressure
range is not known, always start with the 400 psi gauge. When pressure
does not exceed 80 psi, you can retest with the 80 psi gauge. Attach
gauge to hose. DO NOT over tighten.
3. Select the correct adapter for your application (transmission/engine test
port) from the set.
4. Remove vehicle test port plug and fasten the adapter to the test port. DO
NOT over tighten. Soft metal threads can be easily damaged.
5. Connect the hose and gauge to the adapter, taking care to route the hose
as outlined in SAFETY INSTRUCTIONS.
Always check for leaks at adapters, connectors, and hose and
gauge.
6. Start the engine and check for leaks. If leaks are observed, turn off the
engine immediately and correct all leaks before proceeding with test.
7. Read gauge. If gauge reading reaches maximum reading on 80 psi
gauge, turn off the engine immediately and allow engine to cool before
disconnecting the hose and gauge. Then repeat the test procedure
above, using the 400 psi gauge to test system.
8. When pressure test is complete, put vehicle in Park (automatic
transmission) or Neutral (manual transmission), set parking brake as
necessary, and turn engine off. Disconnect the hose and gauge.
Disconnect the adapter and replace vehicle test port plug. Start the
engine and check for leaks at the test port.
9. Check fluid level and refill or drain system as necessary.
!
