16
3. SETUP
continued …
SETTING UP THE PROCESSOR
Upon entering the setup menu your display will show the menu below. Only 8 menu items can be displayed
at once – for clarity this manual shows each menu with all its items. On-screen display is recommended
although the front panel shows similar information, one item at a time. If the default video output settings do
not work with your display, use the front panel display to set video output.
On-screen display is available from the following video outputs:
AVM 40 – MAIN HDMI (at 480i/576i) and S-Video, ZONE2 S-Video
AVM 50 – MAIN HDMI, Component (processed) and S-Video, ZONE2 S-Video
To go to a submenu, highlight a menu item and press SELECT. Each on-screen menu also has a scrolling help
line at the bottom as shown above.
3.1 VIDEO OUTPUT
Highlighting VIDEO OUTPUT then pressing SELECT displays this menu:
ANTHEM AVM 50 SETUP
1. VIDEO OUTPUT
2. SET TIME / TIMERS
3. SPEAKER CONFIG
4. LISTENER POSITION
5. LEVEL CALIBRATION
6. SOURCE SETUP
7. SOURCE PRESETS
8. ANALOG INPUT LEVELS
9. ADC / AUDIO OUTPUT
10. VOLUMES / PATH NAMES
11. TRIGGER / IR / RS232
12. DISPLAYS / TIMEOUT
13. SAVE / LOAD SETTINGS
14. LOCKOUT / PASSWORDS
SELECT Enters Submenu
1. VIDEO OUTPUT
a. VIDEO OUT CONFIG 1
b. VIDEO OUT CONFIG 2
c. VIDEO OUT CONFIG 3
d. VIDEO OUT CONFIG 4
