10. Bolt the lower mount to the bottom
of the air spring using a 3/8” x 3/4"
bolt, lock washer and flat washer.
Before tightening, make sure it aligns
with the lower arm.
7. The stud should poke through the
hole in the upper coil spring pocket.
Some cars may not have this hole and
it must be drilled. Fasten with a 7/16”
Nylok nut and flat washer.
8. Fasten the aluminum bump stop
spacer to the frame using a 3/8” x 1”
bolt, flat washer and lock washer.
9. Screw the bump stop into the
spacer.
