Ridetech 11306699 - Manual

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11306699
67-70 Impala Rear Upper StrongArm & Panhard Bar Kit
Upper Arm Components:
1 90001117 Upper StrongArm
– C-C 10.00”
1 90001589 Kevlar lined Heim end -
.75” thread x .625” I.D.
1 99752004 3/4”-16 SAE jam nut
2 90002066 Aluminum bearing spacer
1 90001085 Poly busing half
1 90001089 Poly busing half
1 90000722 Inner bushing sleeve - 2.625" long x .625" I.D x .75" O.D.
Panhard Bar Components:
1 90000998 Panhard bar – TW 33.875” (C-C 35.75”)
1 90001942 Rubber bushing – Pressed into panhard bar
1 90001946 Kevlar lined Heim end -
.75” thread x .75” I.D.
1 99752004
3/4”-16 SAE jam nut
2 90000724 Aluminum T-bushing
1 90000461 Panhard bar axle stud
Hardware:
2 99621006 5/8” x 3 ¾” SAE Gr. 8 bolt Upper arm
3 99622006 5/8” SAE Nylok jam nut Upper arm / panhard bar stud
1 99561003
9/16” x 3” SAE Gr. 8 bolt
Panhard bar to frame
2 99562001 9/16” SAE Nylok jam nut Panhard bar
1 99563001 9/16 ” USS flat washer Panhard bar stud
1 99603003 5/8
” USS flat washer
Panhard bar stud
