Ridetech 11330601 - Manual

Part # 11330601
63-72 C-10 Master Series SA Front Shock Kit
For Use w/ Lower StrongArms
Shock Assembly:
2 24139999 3.6” stroke single adjustable shock
2 90009988 Short Stud top – 2”
2 90001994 .625” bearing
4 90001995 Snap ring for bearing
Components:
2 90002312 2” Stud top base
2 90001902 Aluminum cap for Delrin ball
2 90001903 Upper Delrin ball half
2 90001904 Lower Delrin ball half
2 90002329 Cantilever pin w/ hardware
4 90002067 Aluminum bearing spacer - .625” I.D.
1 90002301 Driver side upper shock bracket – bolt-on
1 90002302 Passenger side upper shock bracket – bolt-on
Hardware:
8 99371004 3/8” x 1 ¼” USS bolt Upper shock bracket to frame
8 99372002 3/8” USS Nylok nut Upper shock bracket to frame
16 99373003 3/8” SAE flat washer Upper shock bracket to frame
2 99623001 5/8” SAE flat washer Cantilever pin
4 99562002 9/16” SAE jam nut Upper shock stud
