Your MuscleBar installation is now
complete. If you have any further
questions, please call our technical
support line at 812-482-2932.
8. Bolt the 90 degree end of the
PosiLink to the sway bar. A 3/8” flat
washer and 12mm lock washer
must be installed between the
PosiLink and the bar.
9. Bolt the straight end of the
PosiLink to the lower control arm.
An aluminum step washer must be
installed on each side of the control
arm tab. Fasten with a 12mm
Nylok nut. Then tighten the
bushing frame bolts.
6. Apply lithium grease to the poly
bushing. Install the bushing over
the sway bar, and then place the
bushing strap over the bushing.
7. Bolt the sway bar to the frame
plate using two 3/8” x 1 ¼” bolts,
Nylok nuts and flat washers. Do
not tighten yet.
