Ridetech 11019100 - Manual (Page 2)

11019100 Installation Instructions
This sway bar is designed for use with Air Ride Technologies StrongArms.
3. Using a 3/8” x 1 ¼” bolt, flat
washer and Nylok nut, bolt the
frame plate to the bottom of the
frame rail.
4. Make sure the side of the plate
is aligned with the outside of the
frame rail. Drill the remaining
holes.
5. Bolt the outside rear hole of the
plate to the frame using a 3/8” x 1
¼” bolt, Nylok nut and flat washer.
1. The sway bar frame plate will
index off of this factory support
brace rivet. Remove the rivet by
grinding the head smooth, then
drive it out with a hammer and
punch.
2. Drill hole to 3/8”.
