3. Most cars do not have an upper
bar on the driver side, but the 3
bolt holes are there. 7/16” x 1 ¼”
bolts, flat washers and Nylok nuts
are supplied to fasten the bracket
to the frame.
4. Fasten the PosiLink to the upper
bracket using a 10mm Nylok nut.
A 3/8” flat washer needs to be
installed on each side of the
bracket.
1. Loosen the 3 nuts holding the
upper bar bracket to the cross
member on the passenger side of
the car. Remove the reinforcement
plate.
2. Install the new sway bar frame
mount using the 7/16” flat washer
and Nylok nuts supplied. The tab
for the PosiLink will face towards
the outside of the vehicle, the
image below shows the passenger
side.
11289102 Installation Instructions
