19. Bolt the other end of the
StrongArm to the axle using the new
U-bolts supplied.
18. The Stongarms are a direct
replacement of the factory trailing
arms an will bolt to the new tubular
cross member using two 3/4” x 4”
bolts, Nylok nuts and flat washers.
These bushing are polyurethane and
are already lubricated with lithium
grease. Future lubrication can be
done with any non-petroleum based
lubricant.
Note: There is a driver and
passenger side arm. The tabs for the
shock bridge will point towards the
center of the vehicle.
20. Apply thread sealant to a 90-
degree air fitting and screw it into the
top of the air spring. The threads are
already coated with a thread sealant
but we recommend additional
sealant.
21. Secure the air spring to the notch
using two 3/8” Nylok jam nuts and flat
washers.
22. Fasten the bottom of the air
spring to the StrongArm using one
3/8” x 3” bolt, flat washer and lock
washer.
