Hardware Kit
1 5/8” x 2 ¾” SAE Gr.8 Bolt Panhard bar to frame
5 5/8” SAE Nylok Jam Nut Panhard bar & lower shock bridge
2 5/8” x 4” SAE Gr.8 Bolt Lower shock bridge
4 5/8” x 1 ½” SAE Gr.8 Bolt “C” Notch to frame
4 5/8” SAE Nylok Nut “C” Notch to frame
4 5/8” SAE Flat Washer “C” Notch to frame
10 7/16” x 1” USS Bolt Front crossmember to frame
20 7/16” SAE Flat Washer Front crossmember to frame
10 7/16” USS Nyloc Nut Front crossmember to frame
12 7/16” x 1 ¼” USS Bolt “C” Notch & upper shock bridge
12 7/16” x 1” USS Bolt “C” Notch & upper shock bridge
24 7/16 USS Nyloc Nut “C” Notch & upper shock bridge
48 7/16” SAE Flat Washer “C” Notch & upper shock bridge
2 3/8” x 3” USS Bolt Air spring to trailing arm
2 3/8” Lock Washer Air spring to trailing arm
6 3/8” SAE Flat Washer Air spring to trailing arm and to upper mount
4 3/8” USS Nyloc Jam Nut Air spring to upper mount
5 5/16” x 1 ¾” USS Bolt Panhard bar axle bracket to axle cover
5 5/16” Lock Washer Panhard bar axle bracket to axle cover
5 5/16” USS Flat Washer Panhard bar axle bracket to axle cover
2 ¾ X 4” SAE Gr.8 Bolt Trailing Arm to cross member
2 ¾ SAE Gr.8 Nyloc Nut Trailing Arm to cross member
