Ridetech 11226110 - Manual (Page 3)

9. Assemble the spring onto the
Coilover. Assembly is explained on
the next page.
10. Fasten the CoilOver to the upper
bracket using a ½” x 2 ½” bolt and
Nylok nut.
½” I.D. aluminum
spacers must be installed on each
side of the bearing.
11. Fasten the CoilOver to the lower
bracket using a ½” x 2 ½” bolt and
Nylok nut. ½” I.D. aluminum spacers
must be installed on each side of the
bearing.
12. Ride height on this CoilOver is
14.5” from center eye to center eye.
8. Fasten the new upper shock
bracket into the factory shock
location using the 5/16” x 1” bolts, flat
washers and Nylok nuts supplied.
Note: Position the bracket to offset
the shock toward the center of the
car.
