Ridetech 11226110 - Manual

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 11226110
64-
72 GM “A” Body Rear SA CoilOver Kit
For OEM Rear Differential
Shock Assembly:
2 24159999 5” stroke single adjustable shock
2 90002024 1.7” eye w/ rebound adjustment
4 90001994
.625” I.D. bearing
8 90001995 Bearing snap ring
Components:
2 59120225 Coil spring – 12” long / 225 # rate
2 90002222 Spring retainer kit
8 90002043 Aluminum spacer -
.5” I.D.
4 70010828 Delrin Spring Washer
2 90002327 Upper shock bracket
1 90002224 Driver side lower ShockWave bracket
1 90002223 Passenger side lower ShockWave bracket
Hardware:
4 99311001 5/16
”-18 x 1” Gr. 5 bolt
Upper bracket to frame
4 99312001 5/16
”-18 Nylok nut
Upper bracket to frame
8 99313002 5/16 ” SAE flat washer Upper bracket to frame
2 99501027 1/2"-13
x 3 ¾” SAE bolt
ShockWave bracket to trailing arm bracket
4 99501002 1/2"-13
x 1 ½” SAE bolt
ShockWave bracket to factory shock bracket
4 99501003 1/2"-13 x 2 ½” SAE bolt ShockWave to upper and lower bracket
10 99502001 1/2"-13 SAE Nylok nut Lower ShockWave mount and mounting
10 99503001 1/2" SAE flat washer Lower ShockWave mount
