Ridetech 11177199 - Manual (Page 3)

3
7. Raise the upper cradle into position
against the body and clamp in place.
The contour of the plate will match the
contour of the body. On cars that
came with a factory sway bar the two
forward holes on the bottom will
already be there. The rest of the holes
must be drilled with a 5/16” bit. Use
the 3/8” x 1” thread forming bolts to
secure the assembly.
8. Using the cradle as a template, drill
four 3/8” holes in the floor pan.
9. From the inside of the car drop the
reinforcement plates through these
holes. Secure the assembly with 4
3/8” Nyloc nuts and flat washers. You
may need to flatten part of the seam
just above the top two holes.
