15. After the lower axle bracket
crossmember is installed the 4 link bars
can be installed. The lower [non-
adjustable] bars will attach to the oem
leafspring hangars. The upper [adjustable]
bars will attach to the new upper bar frame
brackets. The upper bars are adjusted at
the factory to a xx.xx center to center
distance. There should be no need to re-
adjust these bars.
15. The spare tire must be removed and the mounting crossmember trimmed for airspring
clearance as shown above. The driverside oem upper shock mount will also be removed in this
process. A sawzall is the preferred method. Be sure there is plenty of clearance to the airspring
when fully inflated.
16. Install the panhard bar axle bracket onto the
rearend cover. Be sure to use the longer
fasteners supplied with the system to ensure
proper attachment. NOTE: This bracket may
not be compatible with aftermarket rearend
covers.
