Part # 99010015 Hardware Kit
Note: Lower front bar end utilizes oem leaf spring bolt.
7 m8 x 40mm metric bolts panhard bar axle bracket
7 m8 flat washers panhard bar axle bracket
7 m8 lock washers panhard bar axle bracket
4 ½ x 1 uss bolts lower airspring
8 ½ lock washers lower airspring / upper bridge
2 ½ x 2 ½ uss bolts lower shock mounts
48 ½ x 1 ½ uss bolts upper bar frame mount, upper bridge & c-notch
92 ½ sae flat washers upper bar frame mount, lower airspring, c-notch &
upper bridge
54 ½ nyloc nuts upper bar frame mount, shock, upper bridge &
c-notch
1 5/8 x 1 ¾ sae (gr. 8) panhard bar to axle bracket
1 5/8 lock washer (gr. 8) panhard bar to axle bracket
1 5/8 x 5 ½ sae bolt (gr.8) panhard bar to bridge
6 5/8 x 4 sae bolts (gr. 8) air bar ends
6 5/8 thin nyloc jam nuts air bar ends
8 5/8 x 6 ½ sae bolts (gr. 8) lower bridge to axle
9 5/8 sae nyloc nuts (gr. 8) lower bridge to axle / panhard bar to bridge
17 5/8 sae flat washers (gr. 8) lower bridge to axle / panhard bar to axle bracket
9 3/8 x 1 uss bolts carrier bearing / upper airspring / e-brake cable
9 3/8 uss nyloc nuts carrier bearing / upper airspring / e-brake cable
14 3/8 sae flat washers carrier bearing / upper airspring / e-brake cable
1 5/16 x 1 ¼ uss bolt brake line retainer
2 5/16 uss flat washers brake line retainer
1 5/16 uss nyloc nut brake line retainer
