Tahoe Fastener kit =
6
3/8 x 3/4 uss bolt Airspring mounting
2 3/8 uss nyloc nut Bumpstop stud
8 3/8 sae flatwasher Airspring mounting, bumpstop
8 3/8 lockwasher Airspring mounting,bumpstop
8 7/16 x 1 1/4 uss bolt Upper airspring bracket to frame
16 7/16 flatwasher Upper airspring bracket to frame
8 7/16 uss nyloc nut Upper airspring bracket to frame
10 1/2 x 1 3/4 uss bolt Frame brackets, panhard bar bracket
2 1/2 x 2 1/2 uss bolt Lower shock mount
10 1/2 flatwasher Frame brackets, panhard bar bracket
12 1/2 uss nyloc nut Frame brackets, panhard bar bracket, shocks
2 1/2 x 4” sae Gr. 8 bolt Panhard bar clamp collar
2 1/2 sae Gr. 8 nyloc nut Panhard bar clamp collar
4 1/2 sae Gr. 8 flatwasher Panhard bar clamp collar
8 5/8 x 7” sae Gr. 8 bolt Axle assembly
8 5/8 sae Gr. 8 nyloc nut Axle assembly
16 5/8 sae Gr. 8 flatwasher Axle assembly
2 5/8 x 1 3/4 sae Gr. 8 bolt AirBar rod end
9 5/8 sae nyloc jam nut AirBar rod end
8 5/8 x 2 3/4 sae Gr. 8 bolt AirBar rod end
1 5/8 lockwasher Panhard bar to axle clamp collar
6 3/4 sae jam nut AirBar and panhard bar rod end
6 1/2” flat washers 2 5/8” x 1 3/4” sae grade 8 bolts
8 7/16” x 1 1/4” uss bolts 8 7/16” uss nyloc nuts
16 7/16” flat washers 2 1/2 x 2 1/2 sae grade 8 bolts & nylocs
