Ridetech 12176799 - Manual (Page 2)

350 S. St. Charles St. Jasper, In. 47546
Ph. 812.482.2932 Fax 812.634.6632
www.ridetech.com
Part # 99010032 Hardware Kit
Note: front lower bar utilizes oem spring hanger bolt
8
5/8 x 6 sae bolts
grade 8
bridge to axle assembly
16 5/8 sae flat washers
grade 8
bridge to axle assembly
8 5/8 sae nyloc nuts
grade 8
bridge to axle assembly
8 5/8 x 2 ¾ sae bolts
grade 8
rod ends
8 5/8 sae nyloc jam nuts rod ends
2 ½ x 2 ½ uss bolts lower shock mounting
10 ½ uss nyloc nuts 2=lower shock mounting / 8=upper front bar mount
8 ½ x 1 ½ uss bolts front upper bar mount
16 ½ uss flat washers front upper bar mount
33 7/16 x 1 ½ uss bolts c-notch to frame
66 7/16 uss flat washers c-notch to frame
33 7/16 uss nyloc nuts c-notch to frame
2 3/8 x 1 ¾” USS bolt lower air spring mount
6 3/8 x 1 uss bolts airspring mounting / gas tank x-member
6 3/8 lock washers airspring mounting
10 3/8 sae flat washers airspring mounting / gas tank x-member
2 3/8 uss nyloc nuts gas tank x-member
2 3/8 x 1 ¼ uss bolts upper airspring mount
2 3/8 x 1 ½ uss bolts upper airspring mount
4 3/8 x ¾ uss bolts upper airspring mount
4 7/16 uss flat washers upper airspring mount
4 3/8 uss nyloc nuts upper airspring mount
12 3/8 sae flat washers upper airspring mount
4 3/8 lock washers upper airspring mount
3 5/16 x 1 uss bolts axle cover bracket
3 5/16 sae flat washers axle cover bracket
3 5/16 lock washers axle cover bracket
3 ¼ x 1 uss bolts evap. canister
6 ¼ uss flat washers evap. canister
3 ¼ uss nyloc nuts evap. canister
97 to Present Ford F150 Airbar
