8 Section 61245207L2-5, Issue 3 61245207L2-5C
space bar characters, which are used by the FT1 DP to
determine the speed of the terminal. Once the speed
has been determined, an Introductory Menu will
appear, as illustrated in Figure 6.
From the Introductory Menu, the Main Menu may be
selected. The Main Menu provides access to detailed
performance and configuration information, as
illustrated in Figure 7.
The following screens can be accessed from the Main
Menu:
1. Current System Status
2. Performance History
3. ADTRAN Information
4. Loopback Options
5. Self-Test
6. Provisioning
7. Troubleshooting
Figure 6. Introductory Menu Screen
ADTRAN
901 Explorer Boulevard
Huntsville, Alabama 35806-2807
For Information or Technical Support,
Normal Support Hours ( 7am - 7pm CST ) or Emergency Support Hours ( 7x24 )
Voice Toll Free: 800.726.8663 Fax: 256.963.6217
Voice: 256.963.8100 Internet: www.adtran.com
------------------------------------------------------------------------------
FT1-DP INFORMATION SIGNAL QUALITY FNID INFORMATION SIGNAL QUALITY
-------------------- [ ] 9 -------------------- [ ] 9
S/N : [ ] 8 S/N : DATA NOT AVAIL [ ] 8
CLEI: [ ] 7 CLEI: [ ] 7
MANF: / [ ] 6 MANF: [ ] 6
[ ] 5 [ ] 5
[ ] 4 [ ] 4
[ ] 3 [ ] 3
[ ] 2 [ ] 2
[ ] 1 [ ] 1
[ ] 0 [ ] 0
AT FT1-DP AT FNID
Press “M” to view Main Menu.
ADTRAN FT1 MAIN MENU
1) CURRENT SYSTEM STATUS
2) PERFORMANCE HISTORY
3) ADTRAN INFORMATION
4) LOOPBACK OPTIONS
5) SELF-TEST
6) PROVISIONING
7) TROUBLESHOOTING
Choose a screen by pressing the corresponding number.
Figure 7. FT1 DP Main Menu Screen
